1.
Technical Characteristics:
|
1.1
Principal Methodology |
Difussion/Brazing
bonding |
|
1.2 Dimensiont of charge raw material
|
|
1.3 Maximum temperature in the crucible
|
1800oC
|
|
1.4 Maximum pressure
|
100Mpa |
2. Power:
|
2.1 Power
consumption, KW, peak |
25
|
|
2.2 Primary winding voltage, V |
220
|
|
2.3 Frequency, Hz |
60
|
3. Cooling Water and Gas:
|
3.1 Cooling water
consumption, not above, m3/h |
1
|
|
3.2 Water pressure with the consumption 1m3
/h, kg/cm |
2
|
|
3.3 Water temperature at the input, ℃ |
~25 oC±1 oC |
|
3.4 Water temperature at the output, ℃
|
~30 |
|
3.5 Cooling water debit |
100
lpm
Cooling water should be demineralized, should not contain aggressive
impurity, especially ions of chlorine.
Cooling
water will be anti-rust,alga removal , dust clear .
|
|
3.6 Emergency Cooling Water |
50 lpm minimum, for 24 hours minimum
|
|
